Rohs 21.5 Inch Touch Screen Monitor / Open Frame Lcd Monitor 1000cd/M2

Product Details:
Place of Origin: Guangdong,China
Certification: CE&FCC&Rohs
Model Number: HOP215WPC-8
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: usd 175-179 /pcs
Packaging Details: 59x10x27cm
Delivery Time: 2-8 working days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 50000 pcs/month
Specifications Product Description Request A Quote
Screen Size: 21.5 Inch
Color: Black
Resolution: Black
Interface Type: VGA And HDMI, RS232- Optional
Type: IR Touch , Capacitive Touch
Brightness: 350cd/m2 (1000cd/m2, Optional)
Installation: Kiosk, Embeded, Wall Mount
3M: Support
Material: Metal
High Light:

Open Frame Lcd Monitor 1000cd/M2


21.5 Inch Touch Screen Monitor 1000cd/M2


Rohs 21.5 Inch Touch Screen Monitor

Product Description

Touch monitor 21.5 inch Open Frame Touch Screen Monitor USB HDMI



  • Faceplate surface: anti-glare coating and glare coating; Film thickness: 0.175 and 0.188mm; Glass thickness: 0.7, 1.1 and 1.8mm; Operation pressure: 20 to 150g; Storage temperature: -30 to 80¡ãC;Message noise: 5 to 15m/second; Operating current: 5 to 25mA; Humidity: <95%; Isolation resistance: 20M¦¸¡ü, 25V DC;Sealable against dust, water, oil and static; Advantages: Products insulation point is ¦µ0.03mm
  • Various choices of surface treatments available, special chemical strengthen hard coating,anti-reflection; Has our own factories,so our price is competitive; Excellent sales service; Applications: Light industry; Home appliances; Portable sport devices; Access control terminals; Portable medical devices , anti-Newton,
  • perfect for installation into industrial environments where a PC or computer system is already in use and a new / extra built in display is required. It is a very strong piece of monitoring hardware with 1000 NIT (1000cdm²) panel - making it Lilliput's first fully sunlight readable monitor - and a very capable monitor for industrial and rugged installation.
  • 19 inch Usb/RS232 Touch Screen lcd monitor for machine: USB control ,HDMI D-Sub input,DC 12V/4A input.19" TFT LED panel resalution:1440x900 .brightness 350cd/m2,conrtast ratio 900:1,5 wire line touch screen panel,USB/RS232 control;


Display Specifications
Characteristic Value Comment
LCD Size/Type 21.5”TFT-LCD
Aspect Ratio 16:9
Active Area Horizontal 479 mm
Vertical 270.4 mm
Pixel Horizontal 0.24825
Vertical 0.24825
Panel Resolution 1920(RGB)×1080 (FHD)(60Hz) Native
Display Color 16.7 Million 6-bits + Hi-FRC
Contrast Ratio 1000:1 Typical
Brightness 350 nits Typical
Response Time 5 ms Typical
Viewing Angle Horizontal 178 Typical
Vertical 178
Video Signal Input VGA and DVI , HDMI - optional
Electrical Specifications
Power Supply DC 12V 4A Power Adapter Included
100-240 VAC, 50-60 Hz Plug Input
Power Consumption Operating 38 W Typical
Sleep 3 W
Off 1 W
Touch Screen Specifications
Touch Technology Project Capacitive Touch Screen 10 Touch Point
Touch Interface USB (Type B)
OS Supported Plug and Play Windows All (HID) ,Linux (HID) (Android Option)
Driver Driver Offered
Environmental Specifications
Condition Specification
Temperature Operating -10°C ~+ 50°C
Storage -20°C ~ +70°C
Humidity Operating 20% ~ 80%
Storage 10% ~ 90%
MTBF 30000 Hrs at 25°C



LCD Specification
Active Area(mm) 339.8(H)×272.5(V)
Resolution 1440x900
Dot Pitch(mm) 0.3075×0.3075
Nominal Input Voltage VDD +3.3V(Typ)
Viewing angle (v/h) 60°/70°(CR>5)
Contrast 1000:1
Luminance(cd/m2) 350, 1000cd/m2 - optional
Response Time(Rising/Falling) 5ms/5ms
Support Color 16.2M colors
Backlight MTBF(hr) 50000

Rohs 21.5 Inch Touch Screen Monitor / Open Frame Lcd Monitor 1000cd/M2 0


Touchscreen Specification
Type IR Touch screen
Resolution 4-wires/5-wires touch screen
Light Transmission 92%
Touch Life Cycle 50 millions
Touch Response time 2ms
Touch System Interface USB/RS232 interface
Power consumption +5V@80mA



Rohs 21.5 Inch Touch Screen Monitor / Open Frame Lcd Monitor 1000cd/M2 1

Rohs 21.5 Inch Touch Screen Monitor / Open Frame Lcd Monitor 1000cd/M2 2

Rohs 21.5 Inch Touch Screen Monitor / Open Frame Lcd Monitor 1000cd/M2 3
