OEM 17 Inch Frame Touch Screen Monitor Industrial With CGA VGA

Product Details:
Place of Origin: Guangdong,China
Brand Name: OEM or CNHOPESTAR
Certification: CE&FCC&Rohs
Model Number: HOP170E
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Price can be negotiable
Packaging Details: 59x10x27cm
Delivery Time: 2-8 working days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 50000 pcs/month
Specifications Product Description Request A Quote
Specifications
Specifications
Screen Size: 17 Inch
Color: Black
Resolution: 1280×1024@75Hz
Interface Type: VGA And HDMI, RS232- Optional
Type: IR Touch , Capacitive Touch
Brightness: 250cd/m2 (1000cd/m2, Optional)
Installation: Kiosk, Embeded, Wall Mount
Warranty: 3 Years
3M: Support
Case: Industrial Metal Frame
High Light:

17Inch Frame Touch Screen Monitor

,

CGA Open Frame Touch Screen Monitor

,

VGA Industrial Open Frame Monitor

Product Description

OEM 17 Inch Frame Touch Screen Monitor Industrial With CGA VGA



  • Faceplate surface: anti-glare coating and glare coating; Film thickness: 0.175 and 0.188mm; Glass thickness: 0.7, 1.1 and 1.8mm; Operation pressure: 20 to 150g; Storage temperature: -30 to 80¡ãC;Message noise: 5 to 15m/second; Operating current: 5 to 25mA; Humidity: <95%; Isolation resistance: 20M¦¸¡ü, 25V DC;Sealable against dust, water, oil and static; Advantages: Products insulation point is ¦µ0.03mm
  • Various choices of surface treatments available, special chemical strengthen hard coating,anti-reflection; Has our own factories,so our price is competitive; Excellent sales service; Applications: Light industry; Home appliances; Portable sport devices; Access control terminals; Portable medical devices , anti-Newton,
  • 17 inch Usb/RS232 Touch Screen lcd monitor for machine: USB control ,HDMI D-Sub input,DC 12V/4A input.17" TFT LED panel resalution:1280×1024 .brightness 250cd/m2,conrtast ratio 1000:1,5 wire line touch screen panel,USB/RS232 control;



Specification

General
Series Waterproof and Compact
Monitor Dimensions Width: 368mm Height: 306mm Depth: 55mm
LCD Type 17”SXGA Color TFT-LCD
Video Input VGA and DVI
OSD controls Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply Type: External brick
Input (line) voltage: 100-240 VAC, 50-60 Hz
Output voltage/current: 12 volts at 4 amps max
Mount Interface 1)VESA 75mm and 100mm
2)Mount bracket, horizontal or vertical



LCD Specification
Active Area(mm) 337.920(H)×270.336(V)
Resolution 1280×1024@75Hz
Dot Pitch(mm) 0.264×0.264
Nominal Input Voltage VDD +5.0V(Typ)
Viewing angle (v/h) 85°/88°
Contrast 1000:1
Luminance(cd/m2) 250
Response Time(Rising/Falling) 5s/5s
Support Color 16.7M colors
Backlight MTBF(hr) 30000



Touchscreen Specification
Type Infrared IR touch screen Dual touch
Resolution 4096*4096
Light Transmission 92%
Touch Life Cycle 50 millions
Touch Response time 16ms
Touch System Interface USB interface
Power consumption +5V@80mA
External AC Power Adapter
Output DC 12V /4A
Input 100-240 VAC, 50-60 Hz
MTBF 50000 hr at 25°C
Environment
Operating Temp. 050°C
Storage Temp. -2060°C
Operating RH: 20%80%
Storage RH: 10%90%






Mechanical Drawing

OEM 17 Inch Frame Touch Screen Monitor Industrial With CGA VGA 0





OEM 17 Inch Frame Touch Screen Monitor Industrial With CGA VGA 1

OEM 17 Inch Frame Touch Screen Monitor Industrial With CGA VGA 2

OEM 17 Inch Frame Touch Screen Monitor Industrial With CGA VGA 3

OEM 17 Inch Frame Touch Screen Monitor Industrial With CGA VGA 4












FAQ



1. What is your company's main product?

A:Our main product is digital photo frames, tablet pc , advertising players.



2. Q:What is the minimum order? A: yes, our company mainly deals in wholesale business,but if you insist on buying one, or you only need one set,we will also deliver the goods to you.



3. Q:What payment methods your company accept?

A:We accept most of the payment methods,but mainly accept T/T, Western Union/Alibaba assurance trade payment.



4. Q:I haven't done business with you guys before,how can i trust your company?

A:Our company has been in Alibaba.com for 11,which is longer than most of our fellow suppliers,we've been golden suppliers for years.what's more,we've got quite a lot authority certificates,for example,CE, ROHS, FCC, Alibaba On site checkcertificate.



5. Q:what's the shipment terms and delivery time of your company?

A:Well, they depends on the quantity of your order.As you know ,we need time to manufacture the machines.but mostly ,the shipment time is 3-8 working days after delivery.As for detailed cost, it depends on your final order.



6. Q:I would like to ask you if it's possible to have my logo on the product.

A:Yes, Our one-stop service can be customized according to customer requirements ODM/OEM development design production and processing.
